Seclife H310CDA1 (B250 Chip) 6/7/8/9th M.2 DDR4 S+V+L 1151P Anakart
| Processor |
Support Intel® Socket 1151 for 6th/7th/8th/9th Generation Core™i7/ Core™ i5/Core™ i3/Pentium®/Celeron® Processors Supports Intel® 14 nm CPU Supports Intel® Turbo Boost Technology 2.0 |
| Chipset | Intel® H310C / B250 Chipset |
|
Memory Support |
2 * DDR4 2133MHz DIMM ,Max. 64GB Dual channel memory architecture |
| Graphic |
Integrated Graphics Processor- Intel® HD Graphics support Multi-VGA output support : HDMI / VGA ports |
| Slots |
1 x PCIe x16 3.0/2.0 slot |
| Storage
|
1 x M.2 Socket, Supports 2260/2280 SSD 4 x SATA 6Gb/s Ports |
| LAN | Realtek Chip, 1 x 100M(Optional 1000M) |
| Audio | Realtek Chip, ALC 662 6-channel audio |
| USB | 4 * USB 3.0 port (2 at back panel, blue, 2 at mid-board)
4 * USB 2.0 port (2 at back panel, black, 2 at mid-board) |
| Back Panel I/O |
1 x VGA Port 1 x HDMI Port 1 x Dp 1 x LAN (RJ45) Port 4 x USB 3.1 Gen 1 Ports(Blue) 2 x USB 2.0 Ports 3 x flexible audio jacks |
| Internal I/O |
1 x USB 3.1 Gen 1 connector(19pin), supports 2*USB 3.1 Gen 1 ports 1 x USB 2.0 connector, supports 2*USB 2.0 ports 4 x SATA 6Gb/s Ports
2 x 4 -pin CPU_FAN/SYS_FAN connectors 1 x 24-pin ATX power connector 1 x 4-pin 12V ATX Power connectors 1 x F_Audio connector 1 x Internal Speaker connector 1 x F_Panel connector |
| Dimension | 190 x 170mm |
